Revco® ExF -86C ULT Upright Freezer Operating Manual 7048920 Rev. Thermo Scientific Preface Revco ExF i Part Number Description Quantity 122005 Key 2 (4 DD) 380520 Neoprene Cap 2 510016 ¼-20 x 5½” Bolt 2 195763 Retaining Clip 1 370563 Remote Alarm Connector 1. ULT2586-10-A Revco Ultima PLUS -86°C Upright Freezer 702 Liter 115V Thermo Scientific ULT2586-10-A or ULT2586-10A or ULT258610A We are open for business with regular working hours, see 'Contact Us' link below for our hours of operation. Revco Series ULT Freezers have 5 internal compartments that protect samples by reducing cold air loss and improving temperature recovery time after opening the freezer. Air Filter Access Maintenance is easy with a Revco ExF Ultra-Low Temperature Freezer: simply open the access panel and slide out the air filter for replacement. ULT2586-5-A Revco Elite Series Ultra-Low Temperature Upright Freezer 691L -50° to -86°C 115V Thermo Scientific ULT2586-5-A or ULT2586-5A or ULT25865A We are open for business with regular working hours, See the 'Contact Us' link below for our normal hours of operation.
**TWO YEAR WARRANTY INCLUDED**
Cascade Certified Reconditioned Revco Ultra-low Upright Freezer Model No. ULT2586-9SI-D36
Revco ULT-3030-A18 -30 Freezer Cambridge ID #: 6826 The Revco ULT3030A18 -30°C Freezer features a microprocessor controlled system, gravity air circulation, industrial quality cabinet construction, and extra-strength refrigeration compressors selected for industrial, clinical and scientific use.
The Thermo Scientific Revco Ultima II SI Ultra-Low Temperature Freezer is designed for critical materials storage. This sophisticated freezer provides high security for laboratory samples. Revco SI freezers employ a composite thin wall design to increase interior capacity. Highly efficient thin wall Super Insulation decreases the wall thickness from 5″ (127mm) on conventional ultra-lows to just 2 5/8″ (67mm), maximizing the space available for sample storage. The result: Revco SI freezers offer significantly more storage capacity than conventional models with an equivalent freezer footprint.
Programmable microprocessor control, patented refrigeration system, and state-of-the-art electronics ensure the highest level of sample protection. Revco freezers feature up to 20% more heat removal capacity, 15% less power consumption and 15% less heat emission than comparable ultra-low temperature freezers.
Precise temperature control from -50° to -86°C, adjustable in 1°C increments
Door-mounted, eye-level control panel with easy-to-read LED display and touchpad data entry
Monitoring and Alarm Systems
On-board diagnostics continuously monitor sensors to ensure proper performance
Control Setpoint sets cabinet temperature, Cabinet Temperature displays the temperature
Automatic Incident Monitor (AIM) identifies temperature deviation due to power or temperature failure
Time Delay feature delays restart after power failure
Voltage Buck/Boost corrects line voltage into the unit
Low Voltage Surge Protection minimizes voltage spikes
Life-Guard Alert monitors compressor performance, automatically adjusts to internal and external conditions
Clean Filter, Alarm Battery Low and Voltage indicators
Battery backup supplies control panel in case of power failure
Key-operated main power and alarm switch locks temperature and alarm setpoints
Audible/visual power and temperature failure alarms automatically activate during a temperature deviation
Extreme Ambient Alert warns if room temperature may affect performance
Alarm Test simulates temperature alarm condition
Alarm Reset mutes audible alarm and resets AIM
Remote alarm contacts for external alarm/monitoring system
Construction
High-strength steel cabinet with corrosion-resistant coating
Minimum 5 in. (12.7cm) CFC-free, foamed-in-place urethane insulation (outer door: minimum 3.5 in. [89mm])
Integrated door handle for one-handed operation
Built-in key lock (padlock compatible)
Outer door gasket seals with five points of sealing contact
Inner doors made of high-impact ABS plastic with recessed handles
Stainless-steel interior shelves
Patented Refrigeration System features CFC-free DuPont* Suva* 95 in low stage
1hp industrial-grade compressors
Downfeed evaporator
Washable condenser filter
1 in. (2.5cm) dia. access ports
RS-232 data port
Heavy-duty 2 in. (5cm) locking, tandem wheel casters
Product Specs
Product No. | 8625BU1M-309 |
Model No. | ULT2586-9SI-D36 |
Doors | One, Solid |
Capacity | 25 cu ft |
Temperature | -86 deg C |
Voltage | 208/230V |
Lead Time | 5-10 Working Days |
Included Additional Options | N/A |
